JCD376 USB-C™ 3.1 Fully functional Mini Dock-VGA/ HDMI™/ Ethernet/ USB™ 3.1 HUB/ PD2.0

Please Contact Us For Availability


  • About This Product

      This USB-C™ 3.1 mini docking station converts your laptop’s USB-C™ port into six individual ports, allowing you to create a workstation when you are on the move! Now you can leave those single-function adapters at home.

      The mini dock features an HDMI™ and VGA port so you can easily connect a 4K HDMI™ or a 1080p VGA monitor. It also adds wired network connectivity with an ethernet port and two USB™ Type-A ports for additional peripherals. With USB™ Power Delivery 2.0, you can power and charge your laptop while using the mini dock by simply connecting a USB-C™ power adapter to the USB-C™ power delivery port.

      The JCD376 is perfect for small workspaces, home offices and for on-the-go!


      Features
      • • Easily add a 4K HDMI™ or VGA video output
      • • Reliable network connectivity via the Gigabit Ethernet port
      • • USB-C™ power delivery 2.0 provides charging power to the connected devices
      • • USB™ 3.1 Gen 1 provides up to 5 Gbps transfer rate, which is 10x faster than USB™ 2.0
      • • Plug-and-play, no driver installation is required

  • JCD376 Support

  • JCD376 Specifications

    • System Requirements:

      • Available USB-C™ port that supports DisplayPort™ Alt Mode and USB™ Power Delivery 2.0 or 3.0. Please refer to the manufacturer of your computer for more information on your hardware specifications.

      • Required graphics card:
      - DisplayPort™ 1.2 is required to achieve 4K resolution @ 30 Hz
      - DisplayPort™ 1.1 is required to achieve 1920 x 1200 resolution @ 60 Hz

      Special Notes:
      • • A 4K-capable display is required for obtaining the 3840 x 2160 resolution.
      • • If you are using a high-powered USB™ device, attach the USB-C™ power adapter to the power delivery port to ensure maximum performance. When using your USB-C™ power adapter, the multi-adapter powers both the adapter (with attached peripherals) and your laptop.
      • • To ensure files copy completely, do not remove the USB-C™ power adapter while copying files.

      Hardware
      Warranty 2-Year Limited
      Host Connector USB-C™ 3.1 Gen 1 Male
      Video Output 1 - HDMI™ Female
      1 - VGA Female
      Power Source Bus-powered or self-Powered
      Network Interface RJ45 (Gigabit Ethernet)
      Audio Supported Yes
      Ports 1 - HDMI™
      1 - VGA
      1 - USB-C™ 3.1 Gen 1 with PD 2.0
      1 - USB™ 3.0 Type-A
      1 - USB™ 2.0 Type-A
      1 - RJ45 Gigabit Ethernet

      Performance

      Maximum Display Resolution HDMI™: 3840 x 2160
      VGA: 1920 x 1080
      Maximum Display Refresh Rate HDMI™ @ 30 Hz
      VGA @ 60 Hz
      Maximum Data Transfer Rate 5 Gbps
      Displays Supported 1 (HDMI™ or VGA)
      Compatible Networks 10/100/1000 Mbps
      Audio Channel 2.1 via HDMI™
      Power
      Power Delivery Up to 60W via USB-C™
      Power Consumption ≤ 500 mA
      Input Voltage Up to 20V
      Input Current Up to 3A
      Output Voltage Up to 20V
      Output Current Up to 3A

      Physical Specifications

      Color Champagne Metallic
      Enclosure Type Aluminum
      Cable Length 7.87 in. (200 mm)
      Product Height 4.53 in. (115 mm)
      Product Width 2.1 in. (53.3 mm)
      Product Depth 0.6 in. (15.2 mm)
      Product Weight 3.35 oz (95g)
      Storage Temperature 14 to 149°F (-10 to 65°C)
      Storage Humidity < 85% non-condensing
      Operating Temperature 32 to 104°F (0 to 40°C)
      Operating Humidity < 85% non-condensing

      Package Contents

      • • 1 - JCD376 USB-C™ 3.1 Mini Dock
      • • 1 - Quick Installation Guide

UHD 4K HDMI™ Display

Connect your USB-C™ laptop to a 4K monitor transform your laptop into a workstation. Work more efficiently and get more done with a secondary display connected to your laptop.

4K HDMI™ or 1080p VGA

Featuring two single video output options (HDMI™ or VGA) for your convenience.

USB-C™ 3.1 Gen 1

Additional USB-C™ port supports up to 900 mA downstream charging, Power Delivery 2.0, and data transfer up to 5 Gbps.

Charge Your Laptop

With 60W USB™ Power Delivery, you can power and charge your USB-C™ laptop by simply connecting the adapter to your available USB-C™ port, then connecting a USB-C™ power adapter.

Connect Multiple Peripherals Simultaneously

Optional USB-C™ Power in port helps supply additional power when using it with high-powered USB™ devices or with multiple peripherals at once.

Environmentally Friendly

Recyclable aluminum enclosure is non-toxic and safe for the environment.

Work Anywhere

Its compact and lightweight design allows you to quickly create a mobile workstation anywhere you go.
