JCD543P USB-C™ Triple Display Docking Station with 100W PD Adapter

Please Contact Us For Availability


  • About This Product

      The USB-C™ Triple Display Docking Station provides extra connectivity from your computer. Extend up to three monitors through HDMI™, VGA, and DisplayPort™ or HDMI™. This docking station is designed to be used as a notebook stand, which assists with heat dissipation. With its flexible USB-C™ cord, it keeps in mind the location of the USB-C™ port on your device, ensuring an easy connection.

      These multi-adapters allow you to add an additional USB™ 3.1/SD™/microSD™ computer peripheral, HDMI™/DisplayPort™/VGA monitor and Gigabit Ethernet through your USB™ port. One of the USB™ Type-A ports supports fast charging BC1.2 for a smartphone, tablet or iPad®. The USB-C™ port supports power delivery 3.0, allowing you to keep charging your notebook or smartphone while using the adapter.

      Features:

      • • USB-C™ power delivery 100W pass-through
      • • USB-C™ downstream port Gen 1 5G x1;Power delivery adapter in port x1
      • • USB™ Type-A downstream port Gen 1 5G x3
      • • DisplayPort™ Alt mode supported
      • • DisplayPort™/HDMI™ output 4K @ 30 Hz
      • • USB™ graphic HDMI™ resolution 4K @ 30 Hz; VGA Resolution 1920 x 1080 dual output
      • • RJ45 Gigabit Ethernet
      • • SD™/microSD™ card slots allow for external memory access
      • • Combo audio jack mic/speaker
      • • Cable length 1.5 ft/45 cm

      Prefer your own USB-C™ power adapter? You can buy the docking station by itself here.

      USB-C™ is the new standard for connecting PCs and laptops and will eventually replace all current USB™ cables and connectors. This new USB™ standard can be found on laptops, phones, tablets, etc. USB-C™ has a slim and reversible design, so there is no wrong way to plug it in. USB-C™ offers greater power delivery and faster data transfer rates of up to 5 Gbps.

  • JCD543P Support

    • At j5create we strive to maintain 100% customer satisfaction and functionality, no matter what product or system you may have. We have a full-time team of dedicated technical support specialists waiting to assist you and your specific needs.

      Call Us: 888-988-0488
      Email Us: service@j5create.com

  • JCD543P Specifications

    • Interface

      Host Interface

      USB-C male connector with cable

      Video Interface

      HDMI female connector x 2

      DisplayPort female connector x 1

      VGA female connector x 1

      USB-C™ Port

      USB-C™ downstream port female connector x 1

      USB-C™ power in port female connector x1

      Ethernet Port

      RJ45 female connector (Gigabit Ethernet) x 1

      USB™ Port

      USB™ Type-A 3.1 5G female connector x 3

      Card Slots

      SD™ 3.0 x 1 Slot

      microSD™ 3.0 x 1 Slot

      Combo Audio Jack

      Microphone and speaker


      Power

      Power Mode

      Bus-powered or self-powered

      Functions

      DisplayPort™ Alt Mode

      Display resolution: 4K @ 30 Hz

      HDMI™

      Display resolution: 4K @ 30 Hz

      VGA

      Display resolution: 1920 x 1080 @ 60 Hz

      USB-C™

      Power delivery 3.0 x 1

      USB-C™ 3.1 port x 1

      USB™

      USB™ Type-A 3.1 port x 3 (USB™ 3.1 Gen 1/5 Gbps)

      BC 1.2 port x 1

      Ethernet

      Transfer Rate: 1000 Mbps (Half Duplex)/1000 Mbps (Full Duplex)

      IEEE: IEEE 802.3az, IEEE 802.3, 802.3u, and 802.3ab, IEEE 802.3x

      Modes:

      • • Supports Wake on LAN function, suspend mode and remote wakeup via link-change, Magic Packet™ or Microsoft® wakeup frame
      • • Supports IEEE 802.1Q VLAN tagging and 2 VLAN ID filtering
      Physical Specifications

      Dimensions

      Main body:

      3.24 (W) x 0.92 (H) x 13.78 (D) in.

      82.5 (W) x 23.4 (H) x 350 (D) mm

      USB-C™ cable length: 1.5 ft/450 mm

      Weight

      Main body:

      Approximately: 0.66 lbs./300g


      Environmental

      Storage Temperature

      -10 – 65°C

      Storage Humidity

      < 85% non-condensing

      Operation Temperature

      0 – 40°C

      Operation Humidity

      < 85% non-condensing


      System Requirements

      • • Available USB-C DisplayPort Alt mode
      • • Available USB-C port (USB 3.0 is recommended)
      • • Available USB power delivery over USB-C to support upstream charging
      • • 4K capable graphics card
      • • Microsoft® Windows® 10 or later
      • • macOS® 10.14 or later

      Notes
      • • If you are using a high-powered USB device, attach the USB-C power adapter to the power delivery port to ensure maximum performance.
      • • To ensure files copy completely, do not remove the USB-C™ power adapter while copying files. For maximum performance, use a computer and USB-C™ power adapter equipped with PD 3.0.

      Extended Monitor System Requirements
      • • One 2K (2048 x 1152 @ 60 Hz) full-screen video playback
      • • CPU: Intel® Core™ i5 Quad Core RAM: 4 GB memory or higher
      • • Two 2K (2048 x 1152 @ 60 Hz) full-screen video playback
      • • CPU: Intel® Core™ i7 Quad Core
      • • RAM: 8 GB memory or higher
      • • Higher processor recommended for multi-displays and optimal performance.

      Package Contents
      • • USB-C Triple Monitor Docking Station
      • • Quick Installation Guide
      • • 100W USB-C Power Adapter

      Special Notes

      • Driver installation is required for macOS® and Windows®. If the computer has network access and administrative rights, Windows® can automatically install the driver when the device is plugged in.





  • Simultaneous DisplayPort, HDMI and VGA Output
  • Supports Mirror and Extended modes on both Mac® & Windows®
  • The easiest way to add a second or third display



  • HDMI/DisplayPort/VGA Output Port
  • Supports 3 Video Interfaces
'
  • DisplayPort Alt mode for HDMI or DisplayPort resolution up to 4K @ 30 Hz,
  • HDMI resolution up to 4K @ 30 Hz and VGA resolution up to 1920 x 1080 via dual output



  • Charge your notebook or desktop through the JCD543P

  • SD/microSD Card Reader

  • Easily manage and backup your data from your camera, video recorder and more

  • SuperSpeed USB 3.0 Ports

  • 13 Port Types In One Sleek Design For All Your Needs

  • Double Sided Cable Storage Compartment
  • Place the cable anyway you like

  • Cutting-Edge Design
  • The advanced heat-eliminating design makes the JCD543P the perfect solution for expanding any laptop into a full-sized workstation without the worry of overheating.

  • Cable Storage with Dual Openings

  • Universal Compatibility
  • Compatible with both Mac® & Windows®

  • USB-C 100W PD
  • USB Type-A 5V/2A
  • Power Adapter Included

  • Physical Specifications
